GTIN4052568069131 Festo Proximity Sensor SIEN-M12B-PS-S-L 150403

Name: GTIN4052568069131 Festo Proximity Sensor SIENM12BPSSL 150403
Brand: FESTO
Price: 1 USD

Wholesale GTIN4052568069131 Festo Proximity Sensor SIEN-M12B-PS-S-L 150403 from china suppliers

Brand Name : FESTO

Model Number : SIEN-M12B-PS-S-L

Place of Origin : China

MOQ : 1pc

Price : EXW USD50-60

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 500 pcs per month

Delivery Time : 7-10working days

Packaging Details : Plastic bag, Carton

Type : SIEN-M12B-PS-S-L

Part no : 150403

Brand : FESTO

Weight : 30 g

Mounting type : Flush

Switching status indication : Yellow LED

Contact Now

FESTO Proximity sensor SIEN-M12B-PS-S-L 150403 GTIN4052568069131

About product

Corrosion resistance class CRC 2 to Festo standard FN 940070
Moderate corrosion stress. Indoor applications in which condensation can occur. External visible parts with primarily decorative surface requirements which are in direct contact with a normal industrial environment.
Complete specifications, convenient and fast selection

Technical Data

Conforms to standard	EN 60947-5-2
Symbol	00991701
Approval	RCM trademark c UL us listed (OL)
CE mark (see declaration of conformity)	To EU EMC Directive
Rated operating distance	2 mm
Assured operating distance	1.62 mm
Ambient temperature	-25°C-70°C
Switching output	PNP
Short circuit current rating	Pulsed
Operational voltage range DC	10 V ... 30 V
Reverse polarity protection	For all electrical connections
Electrical connection	3-pin M12x1 Plugs
Size	M12x1
Type of mounting	Via lock nut
Mounting type	Flush
Product weight	30 g
Material housing	Brass PBTP Nickel-plated
Switching status indication	Yellow LED
Ambient temperature with moving cable	-5°C-70°C
Degree of protection	IP65 IP67
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B2-L
Additional information for sensor selection	with standard sensing distance
Electrical output	PNP
Selection of sensor design	Standard

Dimensions – M12

There are many models . Please hurry to me!
